Red Rocker Switch 6 Pin 123-CA1560AB

Red Rocker Switch 6 Pin 123-CA1560AB – DPDT Rocker Switch for Custom Control Systems

The Red Rocker Switch 123-CA1560AB is a 6-pin double pole double throw (DPDT) switch designed for flexibility in dual-circuit control systems. Featuring a red rocker, black body, and compact form factor, it fits standard 22x30mm panel cut-outs, making it a go-to component for automotive, marine, and industrial switching applications.

Built for durability and ease of installation, this DPDT rocker switch is suitable for reversing polarity, switching between power sources, or controlling multiple loads. Its clear actuation and solid design provide reliable performance in high-vibration or heavy-use environments.

Key Features

DPDT Functionality – Double pole double throw switching for dual-circuit control
6-Pin Configuration – Enables advanced wiring setups for reversing or dual load switching
Red Rocker with Black Housing – High-visibility design for quick circuit identification
Standard Panel Mount – Sized for 22x30mm panel cut-outs for easy integration
Durable and Compact – Built for use in tight spaces without sacrificing reliability
Universal Use – Compatible with DC and AC low-voltage systems depending on installation

Benefits

Versatile Circuit Control
Switch between two outputs, reverse motor direction, or control dual circuits from a single point. The DPDT design offers flexible wiring options for technicians and DIY installers.

Fits Standard Panels with No Modifications
Designed to fit 22x30mm cut-outs, it easily drops into common switch panels in vehicles, boats, equipment enclosures, and electrical cabinets.

Rugged Design for Everyday Use
The tactile rocker mechanism and durable pins make it ideal for frequent actuation in custom builds and high-traffic setups.

Useful for Automotive, Marine, and Industrial Projects
Use it to switch lighting systems, power relays, winches, or auxiliary components where precise switching control is needed.

How to Use the Red Rocker Switch 6 Pin 123-CA1560AB

1. Determine Application Needs – Identify whether you need on-on, on-off-on, or polarity-reversing functionality.

2. Prepare the Panel – Ensure your switch panel has a 22x30mm cut-out.

3. Wire the Pins – Connect the two poles and four throws based on your circuit design. Typical setups include reversing motor polarity or toggling between loads.

4. Secure the Switch – Snap the switch into the panel until it locks into place.

5. Test Your Circuit – Power up your system and test switching functionality in both positions.


Follow proper safety practices and ensure circuits are powered down before wiring.

FAQs about Red Rocker Switch 6 Pin 123-CA1560AB

1. What is a DPDT switch used for?
   A DPDT switch allows control of two separate circuits or polarity reversal in a DC circuit. It’s ideal for switching between two sources or loads, or reversing direction in motors and actuators.
2. Can this be used in a 12V DC system?
   Yes, the switch is commonly used in 12V or 24V DC systems in vehicles, trailers, boats, and off-grid electrical setups.
3. What’s the difference between 4-pin and 6-pin rocker switches?
   A 4-pin switch typically operates as SPST or SPDT, controlling one circuit. A 6-pin DPDT switch can manage two independent circuits or allow for more complex switching configurations.
4. Is the switch illuminated?
   This model is a non-illuminated rocker switch. If you require an illuminated version, consider alternatives with built-in neon or LED indicators.
5. Does it fit standard switch panels?
   Yes, the switch fits into a 22x30mm cut-out, a standard size for many automotive, marine, and industrial switch panels.

Order the Red Rocker Switch 6 Pin 123-CA1560AB from Power Start

Looking for a reliable DPDT switch to manage dual circuits or motor direction? The Red Rocker Switch 123-CA1560AB offers a simple, durable solution for automotive, marine, and workshop applications. Order yours today from Power Start and get the switching control your system needs.

Note: Free shipping does not apply to very heavy items that require skids or pallets.
